Intermec EasyCoder F2 – Installation & Operation Ed. 2 35
Chapter 5 Paper Load
Peel-Off
Open the side door.
Turn the printhead lift knob clockwise to lift
the printhead.
The EasyCoder F2 can print on labels, tickets, tags, and paper strip
in various forms. This chapter describes the case when self-adhesive
labels are separated from a backing paper (liner) immediately
after printing after which the backing paper is rewound internally
in the printer.
Peel-off operation cannot be performed when quick-load guides
are fi tted.
Use the <Feed> key (see fi gure #14) when loading the same type of
paper as before. When switching to a new type of media or when the
printer does not feed out the paper properly, simultaneously press
the <Shift> and <Feed> keys.
Peel-off can only be used for:
• Self-adhesive labels on backing paper
An optional label-taken sensor can hold the printing of next label
in a batch until the present label has been removed, see chapter
9 “Options”.
1 2
