Intermec EasyCoder F2 – Installation & Operation Ed. 252
Chapter 6 Setting Up the Printer
Print Speed
The print speed is variable between 100 and 200 mm/sec. Generally,
the lower the speed, the better the printout quality. This is especially
the case when printing bar codes with the bars running across
the paper web (“ladder style”), when printing on demanding face
materials, and when printing at low ambient temperatures. Refer to
the tables under “Media” earlier in this chapter for maximum print
speed values. The default setting is 100 mm/sec.
LTS (Label-Taken Sensor)
The sensitivity of the LTS may need to be adjusted according to
ambient light conditions and refl ective characteristics of the back side
of the paper. The LTS setup options are only displayed if an optional
label-taken sensor is installed in the printer.
• LTS Adjust:
Press <Enter>. A label is feed out. Remove the label and press
<Enter> again. A menu shows the sensitivity automatically
selected by the fi rmware and the range, in which the LTS
will work. Press <Enter> again and you will proceed to the
LTS Test menu.
• LTS Test:
Press <Enter>. A label is fed out. Remove the label and a new label
should be fed out automatically. Repeat until you are sure the LTS
works properly. Then press <Enter> to stop and exit.
• LTS Value:
Press <Enter>. You can enter a new value in the range indicated
in the LTS Adjust menu (see above). Min/max values are
in the range 0–10.
If an optional EasyLAN 100i interface board is fi tted, a number of
additional setup menus will be displayed. These menus are used
for setting up the IP address, the netmask, and the default router
for the EasyLAN 100i board, as described in separate manuals
delivered with the board.
Print Defi nes, cont'd.
Setup Parameters, cont'd.
Network
• IP Selection
• IP Address
• Netmask
• Default router
