Intermec easycoder f2 Installation & Operation Manual

Intermec EasyCoder F2 – Installation & Operation Ed. 286
Appendix 1
Printing
Print Technique Direct Thermal
Printhead Resolution 8 dots/mm (203.2 dpi)
Print Speed (variable) 100 – 200 mm/sec. (≈ 4 – 8"/sec.)
Print Width (max) 56 mm (2.2)" = 448 dots
Print Length (max) 32767 dots = 409.5 cm
1
Media Width (min/max) 25 – 60 mm (1 – 2.36") Standard paper guide
Media Width (min/max) 40 – 60 mm (1.57 – 2.36") Quick-Load guides
Paper Roll Diameter (max) 213 mm (8.38") Short door/no rewind
Paper Roll Core Diameter 38 – 40 mm (1.5") or 76 mm (3") w. adapter
Print Directions 4
Modes of Operation
Tear Off Yes
Peel Off Optional
Firmware
Operating System Intermec Fingerprint 7.31 Incl. Direct Protocol
Smooth Fonts TrueDoc and TrueType fonts
Built-in scalable fonts (std) 15 Unicode fonts
2
Built-in bar code symbologies (std) 36
Startup Program (std) Intermec Shell 4.4
Physical Measures
Dimensions (W x L x H) 194 x 397 x 178 mm (7.64 x 15.63 x 7.00") w. Long side door
Weight (excluding media) ≈ 5.5 kgs (12 lbs)
Ambient Operating Temperature +5°C – +40° C (+41°F – +104° F)
Humidity 20 –80% non-condensing
Electronics
Microprocessor 32 bit RISC
On-board Flash SIMMs 1 – 2 Std. 1 x 2 Mbytes
On-board DRAM SIMM 1 Std. 4 Mbytes
Real-Time Clock Option 10+ years life
Power Supply
Mains Voltage >90 – <264 V AC, 45 – 65 Hz
PFC Regulation IEC 61000-3-2
Maximum Power Consumption Continuous 140 W; Peek 300W
Sensors
Label Gap/Black Mark/Out of Paper Yes 5 fi xed positions
Printhead Lifted Yes
