Intermec PD41

Appendix A — Specifications
PD41 and PD42 Commercial Printer User’s Manual 93
Print Speed and Resolution
Specification Description
Print Mode Direct Thermal
Thermal Transfer
Print Speed (variable) 50.8 to 152.4 mm/sec (2 to 6 in/sec) at 8
dots/mm 203 dpi
50.8 to 101.6 mm/sec (2 to 4 in/sec)
at 11.8 dots/mm 300 dpi
Printhead Resolution 8 dots/mm (203 dpi)
11.8 dots/mm (300 dpi)
Print Width (max) 104 mm (4.095 in)
105.7 mm (4.161 in) at 8 dots/mm 300 dpi
Media Width (min/max) 25 to 118 mm (1 to 4.6 in)
114 mm (4.5 in) with cutter
Media Roll Diameter (max) 213 mm (8.4 in)
190 mm (7.5 in) with internal rewinder
Medial Roll Core Diameter 38 to 40 mm (1.5 in) or 76 mm (3 in)
Media Thickness 60 μm to 250 μm (2.3 to 9.8 mils)
Ribbon Width (min/max) 30 to 110 mm (1.18 to 4.33 in)
Ribbon Roll Diameter (outer)
(max)
76 mm (2.99 in)
450 m (1475 ft) of ribbon
Ribbon Roll Core Diameter
(inner)
25.4 mm (1.00 in)
