Intermec PD41 User Manual

Chapter 4 — Troubleshooting and Maintaining the Printer
PD41 and PD42 Commercial Printer User’s Manual 81
Adjusting Printhead Pressure
The pressure of the thermal printhead against the platen roller is
adjusted at the factory. You may need to readjust the printhead
pressure if the printing is weaker on one side of the media, or if the
thermal transfer ribbon starts to crease (indicated by unprinted white
streaks along the media feed direction).
To adjust the printhead pressure
1 If you have installed thermal transfer ribbon, remove it.
2 Pull out on the printhead lever and turn it counterclockwise to lift
the printhead.
Note: Before adjusting the printhead pressure, try to move the outer
balance box as described in the the previous procedure, “Adjusting
Printhead Balance.”

Intermec PD41 Specifications

General

Resolution	203 dpi
Max Print Width	4.1 inches
Max Print Speed	6 inches per second
Print Method	Direct Thermal; Thermal Transfer
Connectivity	RS-232, USB, Parallel
Optional Connectivity	Ethernet, Wireless
Media Handling	Fan-fold
Media Type	Roll-fed or fanfold labels, tags, and tickets
Media Width	1.0 to 4.65 inches
Memory	8 MB Flash
Operating Temperature	+5°C to +40°C (+41°F to +104°F)
Power Supply	100-240 VAC, 50-60 Hz
