Intermec SR30 User Manual

Appendix A — Specifications and Accessories
30 SR30 Handheld Scanner User’s Guide
Imager Specifications for EA15
The following reading distances apply to the EA15 decoded 2D
area imager (P/N 3-140019-01-01) installed in the SR30.
Symbology Density
Minimum
Distance*
Maximum
Distance
Code 39 0.125 mm (5 mils)
0.20 mm (8 mils)
0.25 mm (10 mils)
1 mm (40 mils)
7.2 cm (3.2 in)
3.8 cm (1.5 in)
3.4 cm (1.3 in)
8 cm (3.1 in)
2.8 cm (5.1 in)
22.5 cm (8.8 in)
27 cm (10.5 in)
83 cm (32.4 in)
EAN/UPC 0.33 mm (13 mils) 5 cm (2 in) 32 cm (12.5 in)
Data
Matrix
0.191 mm (7.5 mils)
0.254 mm (10 mils)
0.381 mm (15 mils)
6.3 cm (2.5 in)
4.8 cm (1.9 in)
*
17.3 cm (6.7 in)
22 cm (8.6 in)
29 cm (11.3 in)
PDF417 0.16 mm (6.6 mils)
0.254 mm (10 mils)
0.381 mm (15 mils)
6.2 cm (2.4 in)
4.5 cm (1.8 in)
4 cm (1.6 in)
15.4 cm (6 in)
23 cm (9 in)
37 cm (14.4 in)
*Minimum reading distances are measured in the dark (0 lux).

Intermec SR30 Specifications

General

Type	Handheld bar code reader
Scanner type	-
Optical sensor resolution	- pixels
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, Code 93, EAN 2, EAN 5, EAN-13, EAN-8, MSI, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Data Matrix
Input voltage	5 V
Power source type	USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	Blue, Grey
International Protection (IP) code	IP30

Weight and Dimensions

Width	72.5 mm
Weight	190 g
