Intermec SR30 User Manual

Chapter 2 — Connecting and Configuring the SR30
8 SR30 Handheld Scanner User’s Guide
Connecting Your SR30 to a Host Device
To connect your SR30 to a host device, you need the appropriate
accessory cable. For a list and description of each cable, see
“Cable Accessories” on page 34.
To creating a USB connection
1 Make sure that you have the USB cable (P/N 236-164-xxx).
2 Turn on your host device.
3 Connect the cable to your SR30 and host device.
4 If necessary, configure your SR30 for an International
keyboard. The default keyboard is North America. For help,
see “International Keyboard Bar Codes” on page 12.
To create an RS-232 connection
1 Make sure that you have the appropriate RS-232 cable
(P/N 236-159-xxx, P/N 236-161-xxx, P/N 236-166-xxx,
or P/N 236-167-xxx) for your host device and appropriate
power supply (if necessary).
2 Turn off your host device.
3 Connect the cable to your SR30 and host device.
To host device
To host device

Intermec SR30 Specifications

General

Type	Handheld bar code reader
Scanner type	-
Optical sensor resolution	- pixels
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, Code 93, EAN 2, EAN 5, EAN-13, EAN-8, MSI, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Data Matrix
Input voltage	5 V
Power source type	USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	Blue, Grey
International Protection (IP) code	IP30

Weight and Dimensions

Width	72.5 mm
Weight	190 g
