Intermec SR30 User Manual

Chapter 2 — Connecting and Configuring the SR30
SR30 Handheld Scanner User’s Guide 9
4 If you are using the external power RS-232 cable, connect the
power supply to the RS-232 cable and an AC power outlet.
5 Turn on your host device.
6 If necessary, configure your SR30 serial parameters to match
the host device.
The default serial parameters for the SR30 are:
Baud Rate: 19200
Data Bits: 8
Parity: none
Stop Bits: 1
For help, see “Serial Parameter Bar Codes” on page 14 or
EasySet version 5.6.0.0 or later. EasySet is available on the
Intermec web site at www.intermec.com/EasySet.
To create a keyboard wedge connection
1 Make sure that you have the keyboard wedge cable
(P/N 236-162-xxx) and appropriate power supply (if
necessary).
2 Turn off your host device.
3 Connect the cable to your SR30 and host device.
To host device
AC power supply

Intermec SR30 Specifications

General

Type	Handheld bar code reader
Scanner type	-
Optical sensor resolution	- pixels
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, Code 93, EAN 2, EAN 5, EAN-13, EAN-8, MSI, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Data Matrix
Input voltage	5 V
Power source type	USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	Blue, Grey
International Protection (IP) code	IP30

Weight and Dimensions

Width	72.5 mm
Weight	190 g
