Chapter 2 — Connecting and Configuring the SR30
10 SR30 Handheld Scanner User’s Guide
4 Connect the power supply to the keyboard wedge cable and
an AC power outlet.
5 Turn on your host device.
6 If necessary, configure your SR30 for an International
keyboard. The default keyboard is North America. For help,
see “International Keyboard Bar Codes” on page 12.
To create a keyboard wedge (Y cable) connection
1 Make sure that you have the keyboard wedge cable
(P/N 236-204-xxx) and appropriate power supply (if
necessary).
2 Turn off your host device.
3 Connect the cable to your SR30 and host device(s).
4 Turn off your host device.
5 Connect the cable to your SR30 and host device(s).
AC power supply
To host device
To host devices
AC power supply

Intermec SR30 Specifications

General

Type	Handheld bar code reader
Scanner type	-
Optical sensor resolution	- pixels
Light levels (direct sunlight)	0 - 100000 lx
Linear (1D) barcodes supported	Code 128, Code 39, Code 93, EAN 2, EAN 5, EAN-13, EAN-8, MSI, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Data Matrix
Input voltage	5 V
Power source type	USB
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	0 - 95 %
Product color	Blue, Grey
International Protection (IP) code	IP30

Weight and Dimensions

Width	72.5 mm
Weight	190 g
