Interroll 9006 User Manual

42
Version 1.1 (11/2011) en
Original language
Troubleshooting
9006 Hybrid Control for RollerDrive
Multiple zones run continuously Communication cable is defective,
sending a jog command
Find the farthest zone in the upstream
direction that is running continuously.
Check the communication cables of this
zone.
Different ground of a multiple power
supply
Verify that a common ground is shared
by all supplies.
System reverses or jogs without
prompting
Fuse is blown
If DIP switch 4 and 5 are ON for all
cards, a blown fuse or loss of power
in one 9006 sends a reverse
jog command to all 9006 cards in
the system.
Check the fuses in all 9006 cards of
the system and replace the blown one
(see "Replacing fuse", page 40).
Miswired communication cable Check the communication cables in the
entry zone of the system. Replace the
miswired cables.
Zone stops when package arrives
Zone does not accept package
Zone receives the accumulate signal Check that the zone is not receiving the
accumulate signal from the downstream
zone.
Ensure that there is no jumper installed
from ground to the Accum (L-stop) input
terminal on the 9006 of the
zone where the package stops. If a
switch is used instead of a jumper,
check that the switch is off.
Communication cable to or between
the zones is miswired
Check the communication cables and
replace them if they are miswired.
No power supply of the
9006
Check the power input to
9006
No power supply of the RollerDrive
EC1xx
Verify that the motor wires are
terminated properly.
Communication cable is miswired
between the zone that is operating
and the zone that is not
Replace the cable.
Package stops within a zone Photoeye is not aligned properly Check the alignment of the photoeye.
Speed of the RollerDrive EC1xx is
too slow
Calculate the speed and the distance to
ensure the time limit is not exceeded.
Reset "Learn Mode" (see "Learn Mode
Reset, page 30)
Jammed package Remove jammed packages.
Jammed roller Remove the cause of the jam or replace
the roller.
Symptom Possible cause Help
