43
Version 1.1 (11/2011) en
Original language
9006 Hybrid Control for RollerDrive
Troubleshooting
Package coasts into the next zone
instead of stopping immediately
Package is heavy or has a low
coefficient of friction
Move the photoeye further back into the
zone.
Apply a coating that increases the
friction between the rollers and the
packages.
Zone does not reverse Communication cable to upstream
zone is miswired
Replace the communication cable.
Signal has not been sent and
received properly
Check the output of the upstream
9006 and the input to the
9006.
Different ground of the zones Check that a common ground exists
between bo
th zones.
Sys
tem turns off when several zones
are in use at the same time
Power supply is not sufficient Ensure that the 24 VDC power supply
has adequate power for the system
requirements.
Check that the AC voltage source and
DC voltage power supply are installed
correctly.
9006 does not recognize the
start sensor
Sensor and reflector are not aligned
properly
Check the alignment of the sensor and
reflector.
Check the settings of DIP switch 4
and 5.
RollerDrive EC1xx is not in braking
mode without any packages on the
conveyor system
This is not an error. It is a power-
saving feature. The RollerDrive
EC1xx is in coast mode until it is
commanded to run or accumulate.
Symptom Possible cause Help
