Invacare Action 3 NG User Manual

Invacare®Action3NG
A
Manufacturer’saddress
B
Dateofmanufacture
C
Productdescription
D
Seatwidth
E
Referencenumber
F
Serialnumber
G
Medicaldevice
H
Serialnumberbarcode
I
EAN/HMIbarcode
J
Maximumuserweight
K
Readusermanual
L
Europeanconformity
Readusermanual
Indicatesahazardoussituationthatcould
resultinseriousinjuryordeathifitisnot
avoided.
Indicatesmaximumuserweight
Non-lockingsidepartswarninglabel
Donotliftthewheelchairbynon-locking
sideparts.
Posturebeltinformationlabel
Theposturebelthasthegoodlength,when
there’sjustsufcientspaceforaathand
betweenbodyandbelt.
Recliningmechanicalbackrestinformationlabel
Pushonthebackrestcanes(1)before
operatingthelevers(2),thisistorelease
theauto-lockedsecuritysystem.Thislabelis
attachedtotheupperpartofthebackrest
cane(rightside).
Snaphooksymbols
Dependingontheconguration,somewheelchairsmaybe
usedasaseatinamotorvehicle,somemaynot.
ISO 717
6-19
Tie-downpositionswheretherestraint
systemstrapsmustbeplacedincaseof
transportingtheoccupiedwheelchairina
motorvehicle.Thissymbolisonlyattached
tothewheelchairwhenitisorderedwith
thetransportationkitoption.
101608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
