Invacare®Action3NG
CAUTION!
Iftheknobisnotcorrectlytightened,thepush
handlecouldaccidentallycomeoffthebackrest
tubewhilepushingitupwards.
–Makesurethattheknobisrmlytightened.
3.6Mudguard
Inordertopreventdirtfromthewheelssprayingupwards,
aremovablemudguardcanbetted.Thepositionofthe
mudguardcanbeadjusted.
Removing
1.Pullthemudguardupwardsoutoftheholder.
2.Toadjusthoweasyordifcultitistopullthemudguard
outoftheholder,changethedegreetowhichthe
screwsDaretightened.
Fitting
1.Pushthemudguardintotheholder .
Adjustingtheheight
1.LoosenthescrewBwith10mmspannerinthegroove
Cofthearmresttube.
2.Movethearmrestupwardsordownwardsuntilyou
reachthedesiredheight,whilekeepingscrewBin
place(atthetopedgeoftheholder).
3.TightenthescrewB(5–6Nm).
4.Performthesettingonbothsides.
3.7Armrests
WARNING!
Riskofinjury
Thesiderestsarenotlockedandcanbeeasily
pulledoutupwards.
–Donotliftortransferthewheelchairusingthe
siderests.
–Donotusethesiderestsfortransportation
whencarryingthewheelchairup-ordownstairs.
CAUTION!
Riskofpinching
–Keepyourngersawayfrommovableparts
duringremoving,ttingoradjustingthe
armrest.
22
1608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
