Invacare®Action3NG
4Options
4.1Comfortversion
ItismadeupofarigidshellAandapreformedfoam
cushionBwhichislockedinplacebyhookandloop
fasteners.Thebackrestshellisremovabletoallowthe
foldingofthewheelchair .Thecomfortversionisalways
deliveredinpassiverearwheelpositionforabetterstability.
WARNING!
Riskofinjury
–Neverliftthewheelchairbythebackrestshell.
CAUTION!
Riskofpinching
–Keepyourngersawayfrommovableparts
duringfolding,disassemblingoradjustment.
Removethebackrestshell
1.SlightlyloosenthetwohandscrewsC.
2.SlidetheleversDinwardsuntiltheyareinopen
position.
3.DisengagethehooksEfromtheirsupports.
Installthebackrestshell
1.EngagethehooksEintotheirsupports.
2.SlidetheleversDoutwardsuntiltheyareinlock
position.
3.FirmlytightenthetwohandscrewsAandmakessure
thattheTWOhandscrewsAareproperlytighten.
Itisrecommendedthatthisoperationbeperformed
onlybytheattendant.Itisimportanttoensurethat
thebackrestshelliscorrectlyttedandengaged
atalltimeswhenthechairisinuse.Makesure
thebackrestcushionhookandloopfastenersarein
goodstateandwellpositioned.
4.2Transitversion
Thetransitversionisdesignedtobedrivenonlybythe
attendant.Tofacilitatesidewaystransfersandsavespace,
thewheelchairisequippedwithrearwheelsof305mm
(12”).
Thedistancebetweenthebrakeshoeandthetyre
canbeadjusted.Theadjustmentmustbecarried
outbyaqualiedtechnician.
Themanualbrakes(optionaldrumbrake)areonlyaccessible
totheattendant;operatethehandle(A)tolockthe
wheelchairinparkingposition.
321608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
