Invacare®Action3NG
Twopositionsofthesmallhandrimarepossibleto
facilitatethepropulsion:internalpositionorexternal
position.Makesurethat3screwsBarelockedinto
position.
CAUTION!
Riskofinjury
–Itsrecommendedthatthechangeofcontrol
sideandpositionofthesmallhandrimmustbe
carriedoutbyanauthorizedprovider .
Disengagethetelescopicrearwheelshaft
Tofoldthewheelchairitisnecessarytodisengagethe
telescopicrearwheelshaftC.
1.DisengagethetelescopicshaftCbyslidingonepart
insidetheother.
2.Tofacilitatethisoperationmovethesmallhandrim
forwardstobackwards.
3.Reversetheproceduretoreinstall.
CAUTION!
Riskofaccident
–ThetelescopicrearwheelshaftCisanintegral
partofthewheelchairandtheuserwillbe
unabletopropelthewheelchairwithoutit.
4.4Onearmdrivebylever
TheOnearmdrivebylevercontrolsystem(leftorright
hand)allowstheuserwithlowmusculartonetopropel
thewheelchairwithasinglearm.Theusergripsthedrive
motionleverwhichpropelsthewheelchairfrontwardsor
backwards(reversinggearleverA,centralpositionisthe
neutralgear)thankstoaninandoutmovement;steeringis
performedbysimplyturningthedrivemotionlevertothe
LH/RHsideandbrakingbypullingthedrivemotionlever
backwards.TheOADLsystemisalwaysdeliveredinpassive
rearwheelpositionforabetterstability.
Thedrivemotionlevercanberemovedtofacilitate
transferortomovenexttoatable;loosenthe
handleleverBandpullupthedrivemotionlever .
Reversetheproceduretoreinstall.
Themanualbrakeisalwayslocatedoppositetothe
controlsystem.
CAUTION!
Riskofpinchingorcrushing
Theremaybeaverysmallgapbetweentherear
wheelandthetransmissionslinkswiththerisk
thatyoucouldtrapyourngers.
–Keepyourngersawayfrommovableparts
whenusingtheOADLsystem,alwayskeepyour
handonthehandlever.
341608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
