Invacare®Action3NG
Fronttting
1.Pushthearmrestdownanduntilthefrontrelease
buttonBsnapsintoitsarmrestsockethole.
2.Ensurebuttonprotrudesfullythroughsockethole.
Rearremoving
1.RemovearmrestfromarmrestbracketDbypulling
straightuponthearmrest.
Reartting
1.PositionarmrestsupportCoverreararmrestbracketD.
2.Pushthearmrestdownuntilaclear“click”isheard
whenit’slockedintothearmrestbracketD.
Adjustingtheheight
1.AfterlooseningthexingscrewEwith5mmAllenkey
oralternativelythethumbscrew,ifpresent.
2.AdjusttheheightandtightenthexingscrewE(5
Nm)orrmlytightenthethumbscrew,intothedesired
position.
3.Performthesettingonbothsides.
3.8Legrests
WARNING!
Riskofinjury
–Neverliftthewheelchairbythefootrest
supportsorlegrests.
CAUTION!
Riskofpinchingorcrushingngers
Thereareswingmechanismswhereyoucould
trapyourngers.
–Becarefulwhenusing,swinging,disassembling
oradjustingthesemechanisms.
IMPORTANT!
Riskofdamagetothelegrestmechanism
–Donotplaceanythingheavy,orletchildren
sitonthelegrest.
3.8.1Swingawaylegrests
Swingingoutwards
1.ActivatethereleaseleverAandswingthelegrests
totheoutside.
261608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
