Invacare Action 3 NG User Manual

TechnicalData
11TechnicalData
11.1Dimensionsandweight
Alldimensionandweightspecicationsrefertoawiderange
ofthewheelchairinastandardconguration.Dimension
andweight(basedonISO7176–1/5/7)mayalteraccording
todifferentcongurations.
IMPORTANT!
–Insomecongurations,theoveralldimensions
ofthewheelchairwhenitisreadyforuse
exceedstheauthorisedlimitsandtheaccessto
emergencyescaperoutesisnotpossible.
–Insomecongurations,thewheelchairexceeds
thesizerecommendedfortravellingbytrain
intheEU.
Maximumuserweight125kg
A
Overalllengthwithleg
rests
962–1185mm
B
Overallwidth
570–710mm
Foldedlength
765–1200mm
Foldedwidth
285–355mm
Foldedheight
795–1510mm
Totalmassfrom12,7–28,2kg
Massoftheheaviest
part
7,5–12,4kg
Staticstability
Downhill:0°–17°
Uphill:0°–7°
Sideways:0°–17°
Seatplaneangle
0°–8°
C
Effectiveseatdepth
395–500mm
D
Effectiveseatwidth
370–505mm,
inincrementsof25mm
E
Seatsurfaceheightat
frontedge
345–550mm,
inincrementsof25mm
F
Seatsurfaceheightat
rearedge
345–550mm,
inincrementsof25mm
1608467-E73

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
