Invacare Action 3 NG User Manual

Options
Adjustthepropulsioneffort
Theadjustmentisperformedbymovingthetransmission
linkssleeveonthedrivemotionlever .
1.SlightlyloosenthehandleleverC.
2.Slidethetransmissionlinkssleevedownwardstoreduce
thestress.
3.FirmlytightenthehandleleverCandmakessurethat
thehandleleverCisproperlytighten.
CAUTION!
Riskofpinchingorcrushing
–Makesurethatthe2handleleversBand
Careproperlypositionedsothattheyare
notbothersomeorhurtfulfortheuserand
attendant.
Disengagethesteeringmechanism
Itmaybenecessary,fortheattendanttomovethe
wheelchair,todisengagetheballjointsystemfromthefork
inordertoreleasethefrontdirectionalwheel.
1.PresstheendofthedisengagingspringD.
2.ReleasetheverticalaxleEfromitssupport.
3.Reversetheproceduretoreinstall.
4.5Posturebelt
Thewheelchaircanbeequippedwithaposturebelt.It
preventstheuserfromslidingdownwardinthewheelchair
orfromfallingoutofthewheelchair .Theposturebeltis
notapositioningdevice.
WARNING!
Riskofseriousinjury/strangulation
Aloosebeltcanallowtheusertoslipdownand
createariskofstrangulation.
–Theposturebeltshouldbemountedby
aqualiedtechnicianandttedbythe
responsibleprescriber.
–Alwaysmakesurethattheposturebeltis
tightlyttedacrossthelowerpelvis.
–Eachtimetheposturebeltisused,checkifit
tsproperly.Changingtheseatand/orbackrest
angle,thecushionandevenyourclothes
inuencethetofthebelt.
1608467-E35

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
