Invacare Action 3 NG User Manual

Options
1.ThreadtheloopFthroughthexationonthechairG
andthenthroughBOTHplasticbucklesH.
4.6Headrest
Theheightandtheremovalareoperatedbythe
handwheel.Thebarisequippedwithanadjustable
stopblock.
Heightadjustment
1.LoosenthescrewinthestopblockB.
2.LoosenthehandwheelA.
3.Adjusttheheadresttothedesiredposition.
4.Re-tightenthehandwheelAdowntothetopofthe
headrestattachment.
5.SlidethestopblockB.
6.Re-tightenthescrew.
Itisnowpossibletoremovetheheadrestand
reinsertitinthedesiredpositionwithoutfurther
adjustments.
Depth/angleadjustment
1.LoosenthehandleD.
2.LoosenthescrewsC.
3.Adjustthedepthandangleoftheheadrest.
4.Re-tightenthehandleandthescrews.
1608467-E37

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
