Invacare®Action3NG
G
Backrestangle
Range:–15°/+30°
Fixed:90°
Adjustable:90°(–15°/+15°),
stepless
Recliner:90°(0°/+30°),
inincrementsof10°
H
Backrestheight
325–610mm
I
Footresttoseatdistance
160–565mm,
inincrementsof10mm
Legtoseatsurfaceangle
0°–90°
J
Armresttoseatheight
Range:170–300mm
N°1:200–280mm
N°2:240mm
N°3:170–295mm
N°4:210–300mm
Frontlocationofarmrest
structure
190–350mm
Handrimdiameter
520–540mm
Horizontallocationof
axle
–55/+42,5mm
Minimumturningradius
790mm
Stowagewidth
250–320mm
Stowageheight
566–1000mm
Stowagelengthfrom695–1130mm
K
Overalllengthwithout
legrests
720–860mm
L
Overallheight
795–1510mm
Pivotwidth
1120–1505mm
Maximumslopeangle
brake
7°
11.2Tyres
Theidealpressuredependsonthetyretype:
TyreMax.pressure
Pneumaticproledtyre:
515mm(20”);560mm
(22”);610mm(24”)
4.5bar450kPa
65psi
Pneumaticlowproletyre:
560mm(22”);610mm
(24”)
7.5bar750kPa
110psi
Schwalbe®MarathonPlus
Evolutiontyre:
610mm(24”)
10bar1000kPa
145psi
Solidtyre:
305mm(12”);
515mm(20”);560mm
(22”);610mm(24”)
---
Solidtyre:
150mm(6”);140mm(5”
1/2);125mm(5”);200
mm(8”)
---
Pneumatictyre:
200mm(8”)
2.5bar250kPa
36psi
74
1608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
