Invacare®Action3NG
4.7Lateralpositioningpads(foradjustable
backrestcoveronly)
WARNING!
Riskoftrapping
–Becarefulnottotrapyourtrunkbetweenthe
twolateralpositioningpadsduringfrontor
lateraltransfers;whentheuserismovingin
thewheelchair .
CAUTION!
Riskofuncomfortableposture
Insufcientspacebetweenthelateralpositioning
padscanbeuncomfortableforcertainusers.
–Thisadjustmentmustbeperformedbya
qualiedtechnicianuponagreementbya
prescribingphysician.
–Consultwithyourprovider .
Thelateralpositioningpadscanbeadjustedinheight
andsideways.
A
B
C
1.RemovethebackrestcushionA.
2.AdjustthelateralpositioningpadsBinheightand
sidewaystotherequiredpositionwiththehooksurface
ofthebackrestcoverC.
3.Ensurethatthetwohooksurfaces(padsandback
cover)aresetcorrectly.
4.PutthebackrestcushionAbackinplace.
≤ 430mm
B
E
D
ThelateralpositioningpadsBmustbelocated
abovethearmpadDinordertobeabletofold
thewheelchair .
Iftheseatwidthislargerthen430mmE,the
lateralpositioningpadsBmustberemoved
beforefoldingthewheelchair .
381608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
