3.4Parkingbrakes
Theparkingbrakesareusedtoimmobilizethewheelchair
whenitisstationarytopreventitfromrollingaway.
WARNING!
Riskofoverturningifyoubrakesharply
Ifyouengagetheparkingbrakeswhileyouare
moving,thedirectionofmovementcanbecome
uncontrollableandthewheelchairmaystop
suddenly,whichcanleadtoacollisionortoyou
fallingout.
–Neverengagetheparkingbrakeswhileyouare
moving.
WARNING!
Riskduetowheelchairbeingoutofcontrol
–Theparkingbrakesmustbeoperated
simultaneously.
–Donotengagetheparkingbrakestoslow
downthewheelchair.
–Donotleanontheparkingbrakesforsupport
ortransfer.
WARNING!
Riskofoverturning
Theparkingbrakeswillnotoperatecorrectly
unlessthereissufcientairinthetyres.
–Ensurethecorrecttyrepressure,11.2Tyres,
page74.
CAUTION!
Riskofpinchingorcrushing
Theremaybeaverysmallgapbetweentherear
wheelandtheparkingbrakewiththeriskthat
youcouldtrapyourngers.
–Keepyourngersawayfrommovableparts
whenusingthebrake,alwayskeepyourhand
onthebrakelever .
Thedistancebetweenthebrakeshoeandthetire
canbeadjusted.Theadjustmentmustbecarried
outbyaqualiedtechnician.
Standardbrake
1.Toengagethebrake,pushthebrakeleverforwardswith
thepalmasfaraspossible.
2.Todisengagethebrake,pullthebrakeleverbackwards
withthelowngers.
14
1608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
