Invacare Action 3 NG User Manual

ProductOverview
Swingingforwards
1.Swingthelegrestforwardsuntilitengages.
Unhinging
1.ActivatethereleaseleverA.
2.Pullthelegrestupwards.
Hinging
1.Hingethelegrestonthefrontoftheframeandswing
itforwardsuntilitengages.
3.8.2Swingaway,angleadjustablelegrests
Swingingoutwards
1.ActivatethereleaseleverAandswingthelegrests
outwards.
Swingingforwards
1.Swingthelegrestforwardsuntilitengages.
Unhinging
1.ActivatethereleaseleverA,swingthelegrest
outwards.
2.Pullthelegrestupwards.
Hinging
1.Pushthelegrestdownintoitsreceiverandswingit
forwardsuntilitengages.
Adjustingangle
Therearesixpresetpositionsavailableforangleadjustment.
1.RotatetheknobDwithonehandwhilesupportingthe
legrestwithyourotherhand.
2.Whenasuitableangleisobtained,letgoofftheknob
andthelegrestwilllockintothedesiredposition.
Swingingcalfpadandadjustments
1608467-E
27

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
