Invacare Action 3 NG User Manual

Invacare®Action3NG
•Swingingcalfpadforwards(1)orbackwards(2):
1.SwingcalfpadEforwards(1).
2.PullupthecalfpadEandswingitbackwards(2).
•Adjustingheightofcalfpad:
1.LoosenknobC.
2.Adjusttothedesiredheightandrmlytightenthe
knob.
•Adjustingdepthofcalfpad
Thecalfpadhasfourdepthadjustmentoptions:
1.RemovethexingscrewFwith5mmAllenkey.
2.Adjusttooneofthefourpositionsandrmly
tightenthexingscrewF(3–5Nm).
Adjustingfootplate
Therearethreedifferentfold-upfootplatesavailable.
•Standardheight-adjustablefootplates:
1.LoosethexingscrewBwith5mmAllenkey.
2.Adjusttheheightandletthescrewcatchoneof
therecessesonthefootplatetube.
3.TightenthexingscrewB(3–5Nm)inthedesired
position.
Thedistancebetweenthelowestpartofthe
footrestandthegroundmustbeatleast50mm.
•Depth-,Angle-(1)andWidth-(2)adjustablefootplates:
1.LoosenthexingscrewGorHwith5mmAllen
key.
2.Adjustthedepthandanglepositionsandrmly
tightenthexingscrewG(12Nm)orH(8–9Nm)
inthedesiredposition.
281608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
