Invacare Action 3 NG User Manual

Invacare®Action3NG
WARNING!
Riskofinjury
–Alwaysmaketheseadjustmentsbeforethe
usersettlesdowninthewheelchairtoprevent
injuries.
–Invacarestronglyrecommendstheuse
ofanti-tippers(availableasanoption)in
combinationwithallrearwheelpositionswhen
youuseyourbackrestwithanangleof12°
andmore
IMPORTANT!
–Pushonthebackrestcanesbeforeoperating
thelevers,thisistoreleasetheauto-locked
securitysystem.
1.Releasetheauto-lockedsystembypushingonthe
backrestcanes.
2.SimultaneouslypulltheleversAtoprovidesthesame
angleonbothsides.
3.Releasetheleverswhenyoureachthedesiredangle.
3.5.7Angleadjustablebackrest(-15°/+15°)
Theangleofthebackrestcanbeadjustedfrom–15°to
+15°(stepless).
1.Adjustthebackrestanglethankstotheadjustablescrew
A.
2.Turn5mmAllenkeyclockwisetoobtainanegative
angle.
3.Alternatively,turn5mmAllenkeyunderclockwiseto
obtainapositiveangle.
4.Ensurebothadjustmentstothedesiredangleareequal
onbothsides.
Invacarerecommendsthatthebackrestangleadjustmentis
carriedoutbyaqualiedtechnician.
181608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
