Invacare Action 3 NG User Manual

Invacare®Action3NG
Unfoldingthebackbrace
1.FoldthebackbraceBupwards.
2.AlignthebackbraceBwiththepushhandleandpushit
downonthehandscrewA.
3.FirmlytightenthehandscrewAandmakesurethat
theTWOhandscrewsAareproperlytightened.
Itisimportanttoensurethatthebackbraceis
correctlyttedandengagedatalltimeswhenthe
chairisinuse.Itshouldnotbelefthangingloose
(seelabelConthebackbrace).
Foldingbackbraceforthebackrest
Anoptionalfoldingbackbraceisavailabletoincreasethe
rigidityofthebackrestonwheelchairswithlargeback
heightsorwidths.
CAUTION!
–Donotusethefoldingbackbracetoliftorpush
thewheelchair .Itcouldbreak.
Foldingthebackbrace
1.UnlockthefoldingbackbracebypushingthejointA
slightlydownwards.
2.Foldthebackbracedownwards.
Thefoldingbackbracewillautomaticallyrelease
whenthechairisfolded.
Unfoldingthebackbrace
1.Foldthebackbraceupwards.
2.LockthefoldingbackbracebypullingthejointAslightly
upwards.
201608467-E

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
