Invacare Bora Series - Adjusting Remote for Length of Users Arm; Adjusting Remote Height; Remote Supports); Adjusting Remote Offset

Setup
5.2.1AdjustingRemoteforLengthofUser'sArm
Fig.5-1
1.LoosenwingscrewA.
2.Adjustcomponenttodesiredposition.
3.Tightenwingscrew.
5.2.2AdjustingRemoteHeight
•3mmAllenkey
Fig.5-2
1.LoosenscrewsA.
2.Adjustcomponenttodesiredposition.
3.Tightenscrews.
5.2.3AdjustingRemoteHeight(onlyforSwing–Away
RemoteSupports)
•6mmAllenkey
Fig.5-3
1.LoosenscrewA.
2.Adjustcomponenttodesiredposition.
3.Tightenscrew.
5.2.4AdjustingRemoteOffset
Theremotecanbeadjustedby20mm(0.8inch)sidewise.
•3mmAllenkey
Fig.5-4
1.LoosenscrewsA.
2.Adjustcomponenttodesiredposition.
3.Tightenscrews.
1528224-Y33
