Invacare Bora Series - 5.20 Manually Height-Adjustable Legrest

Setup
1.Pushreleaseleverinwardoroutward.
2.Adjustcomponenttodesiredposition.
3.Pullupwardtoremovecomponent.
5.19.2AdjustingLength(Standard80°Legrest)
•5mmAllenkey
Fig.5-58
1.Loosenscrew(1).
Donotremovescrew(1).
2.Adjustcomponenttodesiredposition.
3.Tightenscrew.
5.20ManuallyHeight-AdjustableLegrest
5.20.1Swivellingand/orRemovingLegrests(Manually
HeightAdjustable)
Theunlockingknobislocatedonthetopsectionofthe
legrests.Whenthelegrestisunlocked,itcanbeswivelled
totheinsideoroutsidetofacilitategettingin,orcanbe
completelyremoved.
Fig.5-59
1.Pressunlockingknob(1)andremovelegrestsupwards.
5.20.2AdjustingLegrestAngle(ManuallyHeight
Adjustable)
CAUTION!
Riskofcrushing
–Donotreachinsidetheswivellingrangeofthe
legrest.
1528224-Y75
