Invacare Bora Series - 5.18 Powered elevating legrests (ADE legrests)

Setup
1.UsetheAllenkeytoloosenbothsetscrewsonthefoot
plate.
2.Adjusttothedesiredangle.
3.Re-tightenthescrews.
5.17.9Adjustingtheangle–anddepth–adjustablefoot
plate
•5mmAllenkey
1.UsetheAllenkeytoloosenthesetscrewonthefoot
plate(1).
2.Adjustthefootplatetothedesiredangleordepth.
3.Re-tightenthescrew.
5.18Poweredelevatinglegrests(ADElegrests)
5.18.1Swivellingthelegrestoutwardand/orremoving
Thesmallunlockingbuttonislocatedontheuppersection
ofthelegrest.Whenthelegrestisunlocked,itcanbe
swivelledinwardoroutwardwhengettingintowheelchair
aswellasbeingremovedcompletely.
1.Presstheunlockingbutton(1)andswivelthelegrest
outward.
2.Removethelegrestinanupwarddirection.
5.18.2Settingtheangle
CAUTION!
Riskofcrushing
–Donotreachinsidetheswivellingrangeofthe
legrest.
