Invacare®Bora/SpectraXTRSeries
Fig.5-21
1.LoosenscrewsA.
2.Positionjoystickonholder.
3.Tightenscrews.
AdjustingDepthandHeight
Referto5.6.3AdjustingSwing-AwayMechanism,page44.
5.6.2AdjustingEggSwitch
AdjustingSwitchOrientation
Theeggswitchcanbeturnedthrough360degrees.
•7/16inchwrench
Fig.5-22
1.LoosennutA.
2.Adjusteggswitchorientation.
3.Tightennut.
AdjustingDepthandHeight
Referto5.6.3AdjustingSwing-AwayMechanism,page44.
5.6.3AdjustingSwing-AwayMechanism
WARNING!
RiskofInjuryorDeath
Smallpartscanleadtochokinghazardthatmay
resultininjuryordeath.
–Donotremoveanysmallparts.
–Closelysupervisechildren,petsorpeoplewith
physical/mentaldisabilities.
CAUTION!
RiskofInjuryandDamage
Remainingburrsandmissingendcapsafter
modicationsonrods,suchasshortenedrod,can
leadtoinjuryordamage.
–Deburrcutaftercuttingexcessivelength.
–Re-installendcapafterdeburring.
–Checkendcapfortighttting.
Theswing-awaymechanismcanbeusedfordifferent
optionssuchas:
