Setup
1.Removetheplasticcovercapfromtheadjustment
screw(1).
2.Loosenthescrew,usingtheopen-endedspanner13
mm.
3.Setthelegresttothedesiredlength.Takecarenotto
rotatethelowerpartofthelegrestinitssupporttube.
4.Re-tightenthescrews.
5.Re-positiontheplasticcovercap.
5.22.3Adjustingtheangleofthelegrest—Angle
adjustablelegrest
Tools:
•1xopen-endedspanner13mm
•1xopen-endedspanner10mm
•1xAllenkey4mm
1.
Loosenthexationscrews(1)ofthepivotalpointsof
theangeladjustment,usingtheopen-endedspanner10
mmandtheAllenkey4mm.
2.Loosentheclampingscrew(2)oftheangleadjustment,
usingtheopen-endedspanner13mm.
Ontheundersideofthelegresthangerthereisaslit
Aintheoutertube,whichallowsvisualinspection.
Whenadjustingtheangle,theinnertubeDshould
onlyeverbepulledoutsofarthatitsendisush
withtheedgeBoftheclampC.
