Invacare Bora Series - 5.4 Adjustment possibilities for the Flex 2 seat unit

Setup
1.
Releasewingscrew(2).
2.Removethearmrestfromthemounting.
3.
Removethescrew(1)usingthePhillipsscrewdriver.
4.Setthenewarmrestheightbyselectingahigheror
lowerscrewhole.
5.Retightenthescrew.
6.Introducethearmrestintothemountingagain.Tighten
thewingscrew.
7.Repeattheprocessfortheothersideifnecessary.
5.3.2Adjustingthewidthofthearmrests
WARNING!
Seriousinjuryhazardifoneofthearmrests
fallsoutofitsbracketbecausetheyhave
beenadjustedtoawidthwhichexceedsthe
permissiblevalue
–ThearmrestwidthadjustmentfortheFirmseat
unitislimitedonbothsidesbyaspring-loaded
pin.Thislimitingpinmayonlypressedin
toremovethearmrestcompletely(e.g.for
gettinginandout)andnevertoextendthe
widthadjustment.
1.Loosenclampinglever(1).
2.Adjustarmresttorequiredposition.
3.Retightentheclampinglever.
4.Repeatthisprocedureforthesecondarmrest.
5.4AdjustmentpossibilitiesfortheFlex2seat
unit
5.4.1AdjustingwidthoftheFlex2standardarmrest
•8mmAllenkey
1528224-Y35
