Invacare®Bora/SpectraXTRSeries
5.10.3Adjustingthebackrest(Flex2seatunit)—
manuallyusingthegaspressurespring
Thelever(1)foradjustingthebackrestangleislocatedon
theoppositesidefromtheremoteunderthearmrest.If,
forexample,theremoteisinstalledontheright,thelever
islocatedontheleft.
1.Pulltheleverupwards.Adjustthebackresttothe
requiredangle.
2.Releasetheleveragain.
Thebackrestengagesagain.
5.10.4AdjustingBackrestHeight
Thefollowingsectiondescribestheproceduresforadjusting
theheightofthebackrestplate.
Theslingbackisonlyavailableinxedheightsof
48and54cm.
•5mmAllenkey
Fig.5-32
1.LoosenscrewsAandB.
DonotremovescrewsAandB.
2.Adjustcomponenttodesiredposition.
3.Tightenscrews.
5.10.5AdjustingBackrestWidth
Youcanadjustthebackrestplatewidthtoacertaindegree
byadjustingthefrontplate,e.g.inordertoadjustthe
backrestplateinlinewiththeseatcushion.Fairlylarge
adjustmentsmustbemadebyaservicetechniciantothe
rearplateandareoutlinedintheservicemanualforthis
mobilitydevice.
