Invacare Bora Series - Adjusting the Length of the Legrest; Adjusting the Depth of the Calf Pad

Invacare®Bora/SpectraXTRSeries
CAUTION!
Riskofinjuryduetoincorrectadjustmentofthe
footrestsandlegrests
–Beforeandduringeveryjourneyitisimperative
toensurethatthelegrestscontactneitherthe
castorwheelsnortheground.
Theelectricallyheight-adjustablelegrestsareoperatedusing
theremote.Refertotheseparateusermanualforyour
remoteformoreinformation.
5.18.3Adjustingthelengthofthelegrest
CAUTION!
Riskofinjuryduetoincorrectadjustmentofthe
footrestsandlegrests
–Beforeandduringeveryjourneyitisimperative
toensurethatthelegrestscontactneitherthe
castorwheelsnortheground.
•10mmwrench
1.Usethewrenchtoloosenthescrew(1).
2.Adjusttothedesiredlength.
3.Re-tightenthescrew.
5.18.4Adjustingthedepthofthecalfpad
Thedepthofthecalfpadcanbeadjustedviatheholding
plate.Theholdingplateholecombinationsallow5different
depthsettings.
•10mmwrench
1.Usethewrenchtoloosenthenut(1)andremove.
2.Adjusttothedesireddepth.Observethattheround
holesareintendedforthecalfpadretainingscrewand
theoblongholesfortheagletwithoutthread.
3.Screwthenutbackonandtighten.
