Invacare Bora Series - Adjusting Powered Chin Control; Adjusting Extremity Control Joystick; Adjusting Joysticks and Switches on Linkage

Setup
•PROTONwingsofheadarray
•Extremitycontroljoystickforchincontrol
•Eggswitch
•5/32inchAllenkey
AdjustingDepth
1.LoosenscrewA.
2.Adjustrodtodesireddepth.
3.Tightenscrew.
AdjustingPosition
Theswing-awaymechanismcanbeturnedthrough360
degrees.
1.LoosenscrewA.
2.Adjusttodesiredposition.
3.Tightenscrew.
5.7AdjustingPoweredChinControl
WARNING!
RiskofInjuryorDeath
Smallpartscanleadtochokinghazardthatmay
resultininjuryordeath.
–Donotremoveanysmallparts.
–Closelysupervisechildren,petsorpeoplewith
physical/mentaldisabilities.
CAUTION!
RiskofInjuryandDamage
Remainingburrsandmissingendcapsafter
modicationsonrods,suchasshortenedrod,can
leadtoinjuryordamage.
–Deburrcutaftercuttingexcessivelength.
–Re-installendcapafterdeburring.
–Checkendcapfortighttting.
5.7.1AdjustingExtremityControlJoystick
See“AdjustingJoystickOrientation”in5.6.1Adjusting
ExtremityControlJoystick,page43.
5.7.2AdjustingJoysticksandSwitchesonLinkage
PositioningJoysticks/Switches
Riskofdamagetoscrews
Ifyoutightenscrewstoanimpropertorque,they
mighteithercomelooseorgetdamaged.
–Tightenthescrewstoatorqueof3Nm±10%.
1528224-Y45
