Invacare Bora Series - 5.17 Vari-A legrests

Setup
5.16.4Adjustingthelengthofthefootrest
CAUTION!
Riskofinjuryduetoincorrectadjustmentofthe
footrestsandlegrests
–Beforeandduringeveryjourneyitisimperative
toensurethatthelegrestscontactneitherthe
castorwheelsnortheground.
•5mmAllenkey
1.Usethespannertoloosenthescrew(1).
2.Adjusttothedesiredlength.
3.Re-tightenthescrew.
5.17Vari-Alegrests
5.17.1Swivellingthefootrest/legrestoutwardand/or
removing
Thesmallunlockingbuttonislocatedontheuppersectionof
thefootrest/legrest.Whenthefootrest/legrestisunlocked,
itcanbeswivelledinwardoroutwardwhengettingintothe
wheelchairaswellasbeingremovedcompletely.
1.Presstheunlockingbutton(1)andswivelthe
footrest/legrestoutward.
2.Removethefootrest/legrestinanupwarddirection.
5.17.2Settingtheangle
CAUTION!
Riskofinjuryduetoincorrectadjustmentofthe
footrestsandlegrests
–Beforeandduringeveryjourneyitisimperative
toensurethatthelegrestscontactneitherthe
castorwheelsnortheground.
1528224-Y65
