Invacare G40 - Batteries; Light-Servo Module and Lighting System; Drive Electronic and Main Module; Drive Electronic Remote

7
Component
Batteries
Action
> Clean contacts, replace
battery or box
> Tighten, replace.
> Charge battery, replace.
Check
• Damage of battery and
box, corrosion on
contacts
• Check of contacts and
pole clips
• Check battery voltage
!
Light-servo module
and lighting system
> Replace cable, connector
or module.
> Replace lights.
> Replace light bulbs.
• Function servo- and light
module
• Damage of lights
• Function of light bulbs
Speedometer > Replace batteries, cable,
connector, speedometer or
sensor.
• Check function
Drive electronic and
main module
> Replace module.
> Replace cable, connector
or module.
• Status display flashes
• Voltage supply
Drive electronic
Remote
> Tighten, replace.
> Replace.
> Replace remote.
> Replace cable, connector
or panel.
• Attachment
• Cables, plug connec-
tions
• Function joystick
• Voltage supply
Chapter
10.1
bis
10.2
12.3
und
11.0
12.1
12.2
12.4
