Invacare G40 - Inspection Plan; Armrests and Sides; Seat; Backrest with Safety Belt

6
3.0 Inspecton plan
Component
Armrests and sides
Action
> Tighten screws. Repla-
ce overlay.
> Tighten screws. Repla-
ce sides.
> Replace.
Check
• Damage to and attachment
of armrests
• Damage to and attach-
ment of side panels
• Mirrors
Seat > Tighten screws. Repla-
ce parts.
• Damage and screw
fastenings, stitching
Backrest with safety
belt
> Adjust or replacebow-
den wire, gas spring.
> Tighten screws. Repla-
ce parts.
> Replace.
• Adjustment function
• Damage and screw
fastenings, stitching
• Belt and belt buckle
Latching mechanism
of seat in service
position
> Make moving
> Tighten screws.
Replace parts.
• Damage and secure lat-
ching into place
Legrests > Tighten, replace.
> Tighten, replace.
• Welded joint, lock, screw
attachment
• Footboard
Chassis with frame,
side grips and cover-
ing
> Tighten, replace.• Screw attachments, wel-
ded joints, damages
!
Wheel suspension and
wheels
> Replace.
> Replace.
> Adjust, replace.
> Fit on new ones.
• Function and damage of
shock absorbers
• Wheel suspension
• Wheel bearing
• Tyre equipment
Hand brake > Adjust, replace.
> Tighten, adjust,
replace.
> Replace.
• Function
• Loose bowden wires, slee-
ves damaged
• Wear, damage of brake
discs and brake calipers
Drive and steering
asssembly
> Adjust, replace.
> Adjust, replace.
• Check function in driving
and freewheel operation
• Check toggle link
Chapter
7.1
7.5
7.3
7.5
8.1
8.2
bis
8.4
8.5
9.0
7.2
