6.0 Arrangement of assemblies, components and features
G40, front view
G40, side view
1 Leg rests complete, appertaining to seat
system
2 Chassiscovering
3 Seat shell, appertaining to seat system
4 Seat padding, appertaining to seat system
5 Back padding, appertaining to seat system
6 Mirror
7 Front lighting system, integrated in
seat shell
8 Front wheels, powered
9 Back wheel, steerable
10 Frame with back shell 11 and grip
grip 12
13 Sides complete with arm rests
14 Side grip
15 Covering
16 Remote with speedometer
17 Hand brake complete with brake
disc 18
19 Back rest adjusting, complete
20 Walking stick holder
21 Walking stick loop
The following illustrations show the arrangement of the main assemblies, components and features for right-
handed people. The terms are the same as the component terms in the replacement parts catalog.
3
4
5
6
1
1
7
7
2
8
8
9
2
8
9
11
13
14
15
16
17
18
19
20
12
10
21
