SECTION 5—CABINET

Part No 1148070 23 Perfecto

™

SECTION 5—CABINET

Removing Cabinet

 DANGER

Topreventelectricalshock,ALWAYSdisconnectconcentratorfromelectricaloutlet

beforeservicing.

NOTE:Forthisprocedure,refertoFIGURE 5.1.

1. Unplugunit.

2. Removethefourmountingscrewsthatsecurecabinetassemblytothebaseassembly.

3. Liftthecabinetstraightup.

NOTE:Whenrequired,vacuuminsideofthecabinetandexposedfoaminsulation.

4. Tore‐installcabinet,reverseSTEPS2‐3.

FIGURE 5.1 Removing Cabinet

Cabinet Assembly

Mounting

Screws

Base Assembly

Mounting

Screws
