SECTION 22—TIMING

Part No 1148070 75 Perfecto

™

Manual Tuning

NOTE:Forthisprocedure,refertoFIGURE 22.2.

1. Turnpoweroff()andunplugtheunit.

2. Removecabinet.RefertoRemovingCabinetonpage 23.

3. PlugunitinbutDONOTturnon()untilinstructedtobelow.

4. LocatethetimingswitchontheP. C . board.

5. Insertasmallcommonorflatheadscrewdriverintotheadjustmentscrewofthetiming

switch.

6. Setthetimingswitchinitiallyatthenumber“7”position.

7. Turnuniton()andwait15minutesforunittostabilize.

8. Ifafter15minutesofruntimetheconcentrationisbelowspecification,changesetting

toanumberonepositionlowerthantheprevioussetting.

9. Letunitruntenminutes.Ifconcentrationislowerstill,changetheswitchtonumber

twopositionshigher.

NOTE:Yo uwillfindthat theconcentratorwillperformbetterateitherthehigherorlowersetting.

Thenormaladjustmentrangeisbetweentimingpositions3andA.

10. Continuetochangesettingonestepatatime(upordown)untiltheconcentrationis

thehighestvalueachievable.

11. Onceconcentrationhasreachedspecification,retimingiscomplete.

12. Reinstallcabinet.RefertoRemovingCabinetonpage 23.

FIGURE 22.2 Manual Tuning

Manual Timing

Switch

P.C. Board

Control Panel
