SECTION 7—COMPRESSOR

Part No 1148070 33 Perfecto

™

Replacing Capacitor

NOTE:Forthisprocedure,refertoFIGURE 7.2onpage 33.

1. Unplugtheunit.

2. Removethecabinet.RefertoRemovingCabinetonpage 23.

3. Usingneedlenosepliers,disconnectthespadeconnectorsfromthecapacitor

terminals.

4. Cutthetiewrapthatsecuresthecapacitortothebaseoftheconcentrator.

5. Removethecapacitorfromtheconcentratorbase.

6. InstallnewcapacitorbyreversingSTEPS3‐6.

7. Re‐installthecabinet.RefertoRemovingCabinetonpage 23.

FIGURE 7.2 Replacing Capacitor

Capacitor

Capacitor Terminals (Spade

Connectors connect here)

Tie Wrap
