SECTION 7—COMPRESSOR
Perfecto
2
™
32 Part No 1148070
FIGURE 7.1 Replacing Compressor Assembly
Intake Hose
Mounting Screws
Brass Nut
Capacitor
DETAIL “B”
DETAIL “C”
DETAIL “D”
Compressor
Vinyl
Tube
Clamp
Manifold
Assembly
Mounting
Screws
Grommets
DETAIL “A”
Tie-Wrap
Compressor
Capacitor Wires
attach here
