SECTION 6—PREVENTIVE MAINTENANCE

Part No 1148070 29 Perfecto

™

Cleaning the Heat Exchanger

 DANGER

Topreventelectricalshock,ALWAYSdisconnectconcentratorfromelectricaloutlet

beforeservicing.

NOTE:Forthisprocedure,refertoFIGURE 6.6.

1. Unplugunit.

2. Removecabinet.RefertoRemovingCabinetonpage 23.

CAUTION

Usecarenottodeformheatexchangerwheninstalling,removingorcleaning.

3. Removeexcessdirtusingcompressedairorvacuum.

4. Reinstallcabinet.RefertoCabinetonpage 23.

FIGURE 6.6 Cleaning the Heat Exchanger
