Invacare IRC5P Service Manual

SECTION 7—COMPRESSOR
Perfecto
2
™
34 Part No 1148070
Rebuilding the Thomas Model 2660 Compressor
 DANGER
Topreventelectricalshock,ALWAYSdisconnectconcentratorfromelectricaloutlet
beforeservicing.
NOTE:ThiskitisdesignedforrebuildingtheThomasModel2660Seriescompressor.Themodel
numberislocatedonthefrontofthecompressor.Compressornumbersforthiskitare2660CE32,
2660CE37,and2660CE50.Ifthecompressorhasadifferentmodelnumberthanthoselisted,this
kitwillnotwork.
TheThomas2660SeriesCompressorRebuildKit(p/n1109235)containsthefollowing:
DESCRIPTIONQUANTITY
ToolsRequired:
•Torquewrenchthathasaninch‐poundscale(forheadscrews,setscrews,flapper
valvescrew,andpipeplugs)
•Torx
®
T‐25drivefortorquewrench(forheadscrews)
•TorxT‐27drivefortorquewrench(forretainerscrews)
•1/8‐inchAllenwrenchattachmentfortorquewrench(foreccentricsetscrew)
•5/32‐inchAllenwrenchattachmentfortorquewrench
•Flatbladescrewdriverattachmentor1/4‐inchhexsocketfortorquewrench(for
flappervalvescrew)
•Twoflatbladescrewdrivers
•RubberMallet
• Phillipsscrewdriverattachmentfortorquewrench(forretainerscrews)
DESCRIPTION QUANTITY
Teflon®Piston Cups 2
Aluminum Piston Sleeves 2
Flapper Valves - Intake and Exhaust 4
Valve Keepers 4
O-Ring - Sleeve 2
Valve Plate Gaskets 2
Head Mounting Screws 8
Valve Screws 4
Valve Restraints 2
Piston Cup Retainer Screws 2
