Invacare IRC5P Service Manual

TYPICAL PRODUCT PARAMETERS
Perfecto
2
™
8 Part No 1148070
TYPICAL PRODUCT PARAMETERS
Electrical Requirements: 120 VAC ± 10% (132 VAC/108 VAC), 60 Hz
Rated Current Input: Perfecto
2
5: 3 A
Sound Level: Perfecto
2
5: 44 ± 2 dBA Average
Altitude: Perfecto
2
5 - Up to 6,000 ft. (1828 meters) above sea level with-
out degradation of concentration levels. From 6,000 ft. (1828
meters) to 13,129 ft. (4000 meters) below 90% efficiency.
*Oxygen Output
Concentration Levels:
All IRC5PO2/IRC5P models 95.6% to 87% at 0.5 to 5 L/min
Maximum Outlet Pressure: Perfecto
2
5: 5 psi ± 0.5 psi. (34.5 kPa ± 3.45 kPa.)
Flow Range: Perfecto
2
5 - 0.5 to 5 L/min
For flowrates less than 1 L/min, we recommend the use of the
Invacare Pediatric Flowmeter IRCPF16 Accessory.
Low Flow Alarm: Perfecto
2
5 - 0 L/min to 0.5 L/min
Rapid Audible Alarm Beeping (No Accessories Connected).
Average Power
Consumption:
Perfecto
2
5: 280 W (Operating @ 3 L/min)
Pressure Relief Mechanism Operational at: 35 psi ± 3.5 psi (241 kPa ± 24.1 kPa)
Change in maximum recommended flow
when back pressure of 7kPa is applied:
0.7 L/min
Filters: Cabinet, Outlet HEPA and Compressor Inlet
Safety System: Current overload or line surge shutdown. High temperature
compressor shutdown. High Pressure Alarm w/compressor shut-
down. Low Pressure Alarm w/compressor shutdown. Battery
Free Power Loss Alarm. SensO
2
Oxygen System (SensO
2
Model)
Low Flow Alarm.
Width: 15 in. ± 3/8 in (38.1 cm ± 1 cm)
Height: 23 in. ± 3/8 in (58.4 cm ± 1 cm)
Depth: 12 in. ± 3/8 in (30.5 cm ± 1 cm)
Weight: Perfecto
2
5: 43 lbs ± 2 lbs (19.5 kg ± 1 kg)
Shipping Weight: Perfecto
2
5: 48 lbs ± 2 lbs (21.8 kg ± 1 kg)
Operating Ambient
Temperature:
50°F - 95°F (10°C - 35°C) at 20-60% relative humidity
Exhaust: Perfecto
2
5: Less than Ambient
+ 35°F (+19°C).
Oxygen Output: Perfecto
2
5: Less than Ambient + 6°F (+3°C)
Cabinet: Impact Resistant flame-retardant plastic cabinet that conforms to
UL 94-V0.
Regulatory Listing: Double Insulated Product ETL certified complying with UL 1097
ETL certified to CSA C22.2 No. 68.
