SECTION 13—CONTROL PANEL
Perfecto
2
™
54
Part No 1148070
15.
Run
unit
and
check
for
leaks
at
pressure
sensor
tubing
on
product
tank
cap.
Refer
to
Leak
Te
s
t
on
page
76
16.
Reinstall
cabinet.
Refer
to
Removing
Cabinet
on
page
23.
FIGURE
13.1
Removing Control Panel
Circuit Breaker
(STEP 9)
Hour Meter
(STEP 9)
On/Off Switch
(STEP 9)
Mounting
Screws
Control Panel
DETAIL “A”
Tie
Wrap
Tie
Wrap
Control
Panel
DETAIL “B”
¼ Tubing
(STEP 6)
¼ Tubing (STEP 7)
Mounting Screws
(STEP 5)
Control Panel
P.C. Board
53
55
