SECTION 15—P.C. BOARD
Perfecto
2
60 Part No 1148070
FIGURE 15.1 Replacing P.C. Board
Control Panel
Mounting Screw
P.C. Board
Oxygen Sensor
Tubing
(IRC5PO2 only)
Pressure Sensor
Tubing
Mounting Screw
Wiring Harnesses
Connect Here
