INVT Goodrive350 Series User Manual

Goodrive350 series high-performance multi-function inverter Chapter 6
-121-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
Note: Max. output frequency ≥ upper limit
frequency ≥ lower limit frequency.
Setting range: 0.00Hz–P00.04 (upper limit of running
frequency)
P00.06
A frequency
command
selection
0: Set via keypad
1: Set via AI1
2: Set via AI2
3: Set via AI3
4: Set via high speed pulse HDIA
5: Set via simple PLC program
6: Set via multi-step speed running
7: Set via PID control
8: Set via MODBUS communication
9: Set via PROFIBUS / CANopen / DeviceNet
communication
10: Set via Ethernet communication
11: Set via high speed pulse HDIB
12: Set via pulse string AB
13: Set via EtherCat/Profinet communication
14: Set via PLC card
15: Reserved
0
○
P00.07
B frequency
command
selection
15
○
P00.08
Reference object
of B frequency
command
0: Max. output frequency
1: A frequency command
0
○
P00.09
Combination
mode of setting
source
0: A
1: B
2: (A+B)
3: (A-B)
4: Max. (A, B)
5: Min. (A, B)
0
○
P00.10
Set frequency via
keypad
When A and B frequency commands are set by
keypad, the value is the initial digital set value of the
inverter frequency.
Setting range: 0.00 Hz–P00.03 (max. output
frequency)
50.00Hz
○
P00.11
Acceleration
time 1
Acceleration time is the time needed for accelerating
from 0Hz to max. output frequency (P00.03).
Deceleration time is the time needed from
decelerating from max. output frequency (P00.03) to
Depend
on model
○
P00.12
Deceleration
time 1
Depend
on model
○
