Goodrive350 series high-performance multi-function inverter Chapter 6
-164-
Function
code
Name
Detailed parameter description
Default
value
Modi
fy
reset time
interval
times exceeds the value set by P08.29, the inverter
will report fault and stop to wait for repair.
Interval of automatic fault reset: select the interval
time from when fault occurred to automatic fault
reset actions.
After inverter starts, if no fault occurred during 60s,
the fault reset times will be zeroed out.
Setting range of P08.28: 010
Setting range of P08.29: 0.13600.0s
P08.30
Reduction ratio of
droop control
This function code sets the variation rate of the
inverter output frequency based on the load; it is
mainly used in balancing the power when multiple
motors drive the same load.
Setting range: 0.0050.00Hz
0.00Hz
P08.31
Switch-over
between motor 1
and motor 2
0x000x14
Ones: Switch-over channel
0: Switch over by terminal
1: Switch over by MODBUS communication
2: Switch over by PROFIBUS/CANopen/DeviceNet
3: Switch over by Ethernet communication
4: Switch over by EtherCat/Profinet communication
Tens: Motor switch over during running
0: Disable switch over during running
1: Enable switch over during running
0x00
P08.32
FDT1 level
detection value
When the output frequency exceeds the
corresponding frequency of FDT level, multi-function
digital output terminal outputs "frequency level
detection FDT" signal, this signal will be valid until
the output frequency lowers to below the
corresponding frequency (FDT level-FDT lag
detection value), the waveform is shown in the figure
below.
50.00Hz
P08.33
FDT1 lag
detection value
5.0%
P08.34
FDT2 level
detection value
50.00Hz
P08.35
FDT2 lag
detection value
5.0%
